This isolated RS485 + integrated isolated power transceiver series includes smart features that reduce end system install and debug time allowing for easy correction of installation-based connection errors. With the trusted safety of iCoupler digital isolation and IEC 61000-4-2 ESD, signal integrity is maintained in the harshest of environments.
ADM2867E Key Features
- 5.7 kV rms isolated full duplex RS-485/RS-422 transceiver with 8mm creepage
- Margin to CISPR32 Class B emissions on a 2-layer PCB without stitching capacitance
- Cable invert smart feature correct reversed cable connections while maintaining full receiver fail-safe feature
- Flexible supply rails with low voltage to interface to FPGAs and microprocessors and PROFIBUS support with a 5V isolated supply
