Early recognition of fluctuations
The MicroPolar system provides real-time, continuous measurement of moisture or dry matter content in a wide range of products. The measurement is performed directly on the main production line. This microwave measurement is nonintrusive; no sensor comes into contact with the product to be measured, which reduces maintenance. The measurement is not influenced by the colour, viscosity or inhomogeneity of the product. Moreover, the measurement is carried out on the entire product. The MicroPolar system is easy to install. The processing unit has a large display and a user-friendly interface. Calibration can also be performed on site.
The microwaves pass through the product to be measured, causing the free water molecules, which have excellent dielectric properties, to rotate. This rotation causes a slowing down (phase shift) and a decrease in amplitude (attenuation) of the microwaves, resulting in a very accurate measurement of the water content. Thanks to the multi-frequency technique used by Berthold, measurements are highly reliable and stable and are not affected by reflectance or resonance. The integrated reference signal ensures excellent compensation for the influence of environmental parameters. As the device generates very low power microwaves (in the range of 0.1 mW), the measured product is not subject to any temperature increase or change. The radio licenses of the system have been approved by FCC, IC and ETSI.
These are the advantages of Berthold’s moisture measurement used for the food industry:
- Measures moisture across a representative product path
- Energy reduction in drying processes
- Increased yield through reduced amount of rejects
- Free of wear and maintenance
- Online process control for real-time process information
- Highly representative due to transmission principle
- Easy to install on existing pipelines, vessels, and conveyors
For further information please visit this link:
As a world technology leader in the field of radiometric measuring systems, Berthold products convince with outstanding measuring performance and reliability. The main fields of application are, for example, in chemical & polymers (etc. fertilizer industry), steel and power plants, mining & mineral processing, waste & recycling, refineries, paper, glass and as well as in the food industry (etc. sugar beets). In addition, microwave measuring systems for the determination of moisture and concentration belong to our extensive portfolio. The production of high-quality measuring systems for industry and research began more than 70 years ago in Bad Wildbad in the Black Forest.
