"The protected method has been and is being used for the treatment of probably all boron-doped monocrystalline PERC solar cells. Therefore, it is a billion-dollar market in global terms," explains Dr.-Ing. Hubert Siller, Managing Director of TLB GmbH. It is a method that supports increase the efficiency of monocrystalline solar cells, which are mainly produced on the basis of the Czochralski (Cz) technique. Under operating conditions, however, the boron-doped CZ solar cells suffer from so-called light-induced degradation (LID), due to which the efficiency of a CZ-silicon solar cell is considerably reduced after only a short period of exposure to solar radiation. Depending on the material and production process, this can lead to a loss in efficiency of more than one percent absolute.
Scientists at the Photovoltaics Department of the University of Konstanz introduced as early as in 2006 a method to neutralize this type of degradation. The process developed and optimized over years by Axel Herguth, Svenja Wilking and Professor Giso Hahn can easily be integrated into the production process. The scientists made use of the fact that the degraded solar cells can be regenerated by exposing them to light energy greater than 100 degrees Celsius. Alternatively, regeneration can also be achieved using electrical current instead of lighting.
The economic potential of regeneration is enormous: If the degradation-caused loss in efficiency of one percent absolute is nearly completely offset, this yields additional efficiency of approx. five percent. With a 1 GWp production line, we are looking at over ten million euros per year. Another major advantage is the resource conservation that can be realized by regeneration. A higher level of efficiency means that less raw materials and energy are consumed, which in turn leads to a more environmentally friendly production. Operators of solar plants thus benefit from higher yields and end consumers from lower energy costs.
Aus Ideen Werte schaffen – Technologie-Lizenz-Büro (TLB) GmbH ist eine Agentur für Erfindungs- und Patentmanagement in Deutschland. TLB begleitet Erfindungen von Hochschulen, Unternehmen und Erfindern auf ihrem Weg von der ersten Idee bis zum wirtschaftlichen Produkt. Als Partner der Wissenschaft und der Wirtschaft bietet TLB sei mehr als 20 Jahren maßgeschneiderte Services und intelligente Lösungen im Erfindungs- und Patentmanagement.
